Thông số Chống sét xung lan truyền cho đường dữ liệu RS 485_OVR SLRS485
Mã sản phẩm : 7TCA085400R0310
Technical
Nominal AC Voltage of the System (Uo):15 V
Number of Protected Poles:3
Product Main Type:Data SPD
Standards:IEC 61643-21
Discharge Current:I (max, 8 / 20 µs) 10 kA
Maximum Continuous Operating Voltage (Uc):16.7 V
Voltage Protection Level ( Up):27.2 V
Serial Resistance:1 Ω
Product Name:Surge Protective Devices
Suitable For:To protect systems against transient overvoltages or surges from lightning and electrical switching events
